Technical data
Lifting capacity:4200kg
Lifting height:1500mm/1800mm
Jacking height:350mm
Total length:4380mm
Ramp length:1200mm
Total height:2000mm
Total width:2980mm
Power supply:220v/380v
Packing dimension:4400*500*850mm

Lifting machine selling point:
1.body with safety design, which is surrounded by metal from upside, middle, lower part
2.with a alone power switch to control  and increase the safety
3.The chain by using a 10 pcs reinforced chain, much stronger than 7 pcs chain
4. Lifting arms all are fixed by steel strand or Channel. The machine is more stable
Product Features
Can install an adjustable front wheel  and rear-wheel slide plate ,used for all vehicle with different tyre distance.
